| Model： |
X11DPL-i |
| Model： |
X11DPL-i |
| Chipset： |
Intel® C621 |
| Processors： |
2nd Generation Intel® Xeon® Scalable Processors (Cascade Lake-SP), Intel® Xeon® Scalable Processors.Dual Socket P (LGA 3647) supported, CPU TDP support Up to 140W, 2 UPI up to 10.4 GT/s |
| Memory： |
Up to 2TB 3DS ECC RDIMM, DDR4-2933MHz; Up to 2TB 3DS ECC LRDIMM, DDR4-2933MHz, in 8 DIMM slots |
| Expansion slots： |
2 PCI-E 3.0 x16,3 PCI-E 3.0 x8, 1 PCI-E 3.0 x4 (in x8 slot), 1 PCI-E 3.0 x4 (in x8 slot) |
| LAN： |
Dual LAN with Lewisburg Marvell 88E1512 PHY |
| Storage： |
Intel® C621 controller for 10 SATA3 (6 Gbps) ports; RAID 0,1,5,10 |
| Interface： |
M.2 Interface: 1 SATA/PCI-E 3.0 x4 M.2 Form Factor: 2260, 2280 M.2 Key: M-Key |
| USB： |
4 USB 2.0 ports (2 rear + 2 headers), 3 USB 3.0 ports (2 headers + 1 Type A) |
| Graphices： |
1 VGA port |
